FR20C04VB Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
RECEPTACLE, THR, SINGLE ROW, 2.0
| Part | Contact Material | Insulation Material | Contact Shape | Connector Type | Contact Length - Post | Contact Length - Post | Number of Positions | Number of Positions Loaded | Contact Type | Termination | Mounting Type | Insulation Height | Insulation Height | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating | Number of Rows | Insulation Color | Number of Rows [custom] | Contact Length - Post [x] | Row Spacing - Mating | Row Spacing - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | Copper Alloy | Polyester Polyethylene Terephthalate (PET) | Square | Receptacle | 2.2 mm | 0.087 in | 4 | All | Female Socket | Solder | Through Hole | 4.3 mm | 0.169 " | Gold | -40 C | 105 ░C | Push-Pull | 0.079 " | 2 mm | Flash | 1 | Black | ||||
 METZ CONNECT USA Inc. | Copper Alloy | Polyester Polyethylene Terephthalate (PET) | Square | Receptacle | 2.3 mm | 8 | All | Female Socket | Solder | Through Hole | 4.3 mm | 0.169 " | Gold | -40 C | 105 ░C | Push-Pull | 0.079 " | 2 mm | Flash | Black | 2 | 0.091 " | 2 mm | 0.079 in |
