CT427 Series

Catalog

XTREMESENSE TMR ULTRA-LOW NOISE,

Part	Current - Sensing	Operating Temperature [Max]	Operating Temperature [Min]	Number of Channels [custom]	Sensor Type	Package / Case	Package / Case	Package / Case	Accuracy	Sensitivity	Linearity	Mounting Type	Response Time	Frequency [Max]	Frequency [Min]	For Measuring	Supplier Device Package	Voltage - Supply [Max]	Voltage - Supply [Min]	Polarization	Output	Current - Supply (Max) [Max]	Supplied Contents	Sensing Range [Min]	Sensing Range [Max]	Interface	Contents	Utilized IC / Part
Allegro MicroSystems CT427-HSN865DR	65 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	1 %	30.8 mV/A	0.2 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Unidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CTD427-50AC					Current Sensor					20 mV/mT								3.6 V	3 V				Board(s)	-50 A	50 A	Analog	Board(s)	CT427
Allegro MicroSystems CT427-HSN820MR	20 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.5 %	50 mV/A	0.1 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Bidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN850DR	50 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	1 %	40 mV/g	0.2 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Unidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN865MR	65 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.5 %	15.4 LSB/mT	0.2 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Bidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN850MR	50 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.5 %	20 mV/mT	0.1 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Bidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN830DR	30 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.7 %	66.7 mV/A	0.1 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Unidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN820DR	20 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.7 %	100 mV/g	0.1 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Unidirectional	Ratiometric Voltage	9 mA
Allegro MicroSystems CT427-HSN830MR	30 A	125 °C	-40 C	1	Magnetoresistive	0.154 in	8-SOIC	3.9 mm	0.5 %	33.3 mV/°/s	0.1 %	Surface Mount	300 ns	1 MHz	DC	AC DC	8-SOIC	3.6 V	3 V	Bidirectional	Ratiometric Voltage	9 mA
