E2A-M08 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 2MM CYLIND
| Part | Shielding | Sensing Distance | Sensing Distance | Voltage - Supply [Max] | Voltage - Supply [Min] | Sensor Type | Operating Temperature [Max] | Operating Temperature [Min] | Response Frequency | Ingress Protection | Output Type | Output Type | Package / Case | Termination Style | Material - Body | Indicator |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Shielded | 2 mm | 0.079 in | 32 VDC | 10 VDC | Inductive | 85 °C | -40 C | 1.5 kHz | IP67 IP69K | PNP-NO | 3 | Cylinder Threaded - M8 | Connector | Nickel-Plated Brass | LED |
 Omron Automation and Safety | ||||||||||||||||
Omron Automation and Safety | Shielded | 4 mm | 0.157 in | 32 VDC | 10 VDC | Inductive | 85 °C | -40 C | 1 kHz | IP67 IP69K | PNP-NO | 3 | Cylinder Threaded - M8 | Connector | Nickel-Plated Brass | LED |
Omron Automation and Safety | Unshielded | 4 mm | 0.157 in | 32 VDC | 10 VDC | Inductive | 85 °C | -40 C | 1 kHz | IP67 IP69K | 3-Wire NPN-NO | Cylinder Threaded - M8 | Connector | Nickel-Plated Brass | LED | |
 Omron Automation and Safety | Unshielded | 4 mm | 0.157 in | 32 VDC | 10 VDC | Inductive | 85 °C | -40 C | 1 kHz | IP67 IP69K | PNP-NO | 3 | Cylinder Threaded - M8 | Connector | Nickel-Plated Brass | LED |
Omron Automation and Safety | Shielded | 2 mm | 0.079 in | 32 VDC | 10 VDC | Inductive | 85 °C | -40 C | 1.5 kHz | IP67 IP69K | 3-Wire NPN-NO | Cylinder Threaded - M8 | Connector | Nickel-Plated Brass | LED |
