SRR4018 Series

Catalog

IND4.8X4.8X1.8MM,8.2UH30%1.4A,SHDSMD /TAPE & REEL - 7" REEL

Part	DC Resistance (DCR) [Max]	Tolerance	Material - Core	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Inductance	Operating Temperature [Max]	Operating Temperature [Min]	Inductance Frequency - Test	Package / Case	Current - Saturation (Isat)	Frequency - Self Resonant	Shielding	Current Rating (Amps)	Q @ Freq	Type	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type
Bourns Inc. SRR4018-8R2Y	135 mOhm	30 %	Ferrite	0.079 in	2 mm	8.2 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	1.1 A	40 MHz	Shielded	1.4 A	7 7.96 MHz	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-560Y	820 mOhm	30 %	Ferrite	0.079 in	2 mm	56 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	400 mA	15 MHz	Shielded	0.52 A	2.52 MHz 8	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-3R9Y	75 mOhm	30 %	Ferrite	0.079 in	2 mm	3.9 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	1.65 A	60 MHz	Shielded	1.82 A	7.96 MHz 8	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-3R3Y	65 mOhm	30 %	Ferrite	0.079 in	2 mm	3.3 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	1.8 A	61 MHz	Shielded	1.95 A	7.96 MHz 8	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-121Y	1.95 Ohm	30 %	Ferrite	0.079 in	2 mm		125 °C	-40 C	100 kHz	1919 (4848 Metric)	280 mA	10 MHz	Shielded	0.33 A	11 796 kHz	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-680Y	860 mOhm	30 %	Ferrite	0.079 in	2 mm	68 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	380 mA	13 MHz	Shielded	0.5 A	2.52 MHz 7	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
Bourns Inc. SRR4018-270Y		30 %	Ferrite	0.079 in	2 mm	27 µH	125 °C	-40 C	100 kHz	1919 (4848 Metric)	0.6 A	23 MHz	Shielded	770 mA	2.52 MHz 7	Drum Core Wirewound	4.8 mm	4.8 mm	0.189 in	0.189 "	Surface Mount
