STK4.3 Series
Manufacturer: CIT Relay and Switch
Beta
⌘K
SWITCH TACTILE SPST-NO 0.05A 48V
| Part | Switch Travel | Actuator Material | Circuit | Actuator Orientation | Switch Function | Ingress Protection | Outline [x] | Outline [y] | Actuator Type | Illumination | Actuator Height off PCB, Vertical [z] | Contact Rating @ Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Operating Force | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CIT Relay and Switch | 0.25 mm | Polybutylene Terephthalate (PBT) | SPST-NO | Top Actuated | Off-Mom | IP67 - Dust Tight Waterproof | 6.2 mm | 6.2 mm | Standard | Non-Illuminated | 4.3 mm | 0.05 A 48 VDC | 85 °C | -40 C | Through Hole | 260 gf | PC Pin |
 CIT Relay and Switch | 0.25 mm | Polybutylene Terephthalate (PBT) | SPST-NO | Top Actuated | Off-Mom | IP67 - Dust Tight Waterproof | 6.2 mm | 6.2 mm | Standard | Non-Illuminated | 4.3 mm | 0.05 A 48 VDC | 85 °C | -40 C | Through Hole | 160 gf | PC Pin |
