E2E-X14 Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SENSOR INDUCT 14MM PNP M18 NC
| Part | Output Type | Material - Body | Ingress Protection | Sensor Type | Termination Style | Sensing Distance | Sensing Distance | Shielding | Indicator [custom] | Voltage - Supply [Max] | Voltage - Supply [Min] | Package / Case | Response Frequency | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Omron Electronics Inc-EMC Div | PNP-NC 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Connector | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | NPN-NC 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | 2-Wire NPN-NO | Nickel-Plated Brass | IP67 | Inductive | Cable with Connector | 14 mm | 0.551 in | Unshielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 400 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | NPN-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | PNP-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | NPN-NC 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | NPN-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | PNP-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Connector | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
 Omron Electronics Inc-EMC Div | PNP-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Connector | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
Omron Electronics Inc-EMC Div | PNP-NO 3-Wire | Nickel-Plated Brass | IP67 IP69K | Inductive | Cable Leads | 14 mm | 0.551 in | Shielded | LED | 30 VDC | 10 VDC | Cylinder Threaded - M18 | 350 Hz | 70 °C | -25 °C |
