LB15RKG01 Series

Catalog

STD SIZE PUSHBUTTON/ILLUMINATED/

Part	Electrical Life	Mechanical Life	Current Rating (Amps)	Actuator Type	Illumination Type, Color	Termination Style	Switch Function	Illumination Voltage (Nominal)	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Type	Mounting Type	Actuator Marking	Color - Actuator/Cap	Voltage Rating - AC	Operating Temperature [Max]	Operating Temperature [Min]	Circuit	Voltage Rating - DC
NKK Switches LB15RKG01-5D12-JD	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Amber LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	12 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-6B-JB	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	LED White	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	3.3 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-6B-JC	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	LED White	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	3.3 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-5D24-JB	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Amber LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	24 V	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-F	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular		Solder Quick Connect - 0.110" (2.8mm)	On-Mom		16.2 mm	22.4 mm	Standard	Panel Mount Snap-In	No Marking	Green	28 V	70 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-5D-JD	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Amber LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	2 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-5D05-JD	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Amber LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	5 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-6F-JF	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Green LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	3.3 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-6F-JB	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Green LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	3.3 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
NKK Switches LB15RKG01-5F05-JB	100000 Cycles	1000000 Cycles	0.4 VA	Button Rectangular	Green LED	Solder Quick Connect - 0.110" (2.8mm)	On-Mom	5 VDC	16.2 mm	22.4 mm	Illuminated Standard	Panel Mount Snap-In	No Marking	Clear	28 V	50 °C	-25 °C	SPDT	28 V
