RFAA4N Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
RF / COAXIAL ADAPTER, N, JACK, N, JACK, STRAIGHT PANEL ADAPTER, 50 OHM
| Part | Mating Cycles | Body Material | Operating Temperature [Max] | Operating Temperature [Min] | Center Contact Material | Dielectric Material | Adapter Series | Convert From (Adapter End) | Convert To (Adapter End) | Center Gender | Mounting Type | Mounting Feature | Conversion Type | Frequency - Max [Max] | Impedance | Adapter Type | Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | 500 | Stainless Steel | 85 °C | -40 C | Beryllium Copper | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | N to N | Female Socket N Jack | N Jack Female Socket | Female to Female | Panel Mount | Flange | Same Series | 18 GHz | 50 Ohms | Jack to Jack | Straight |
 BULGIN LIMITED | 500 | Stainless Steel | 85 °C | -40 C | Beryllium Copper | Polyetherimide (PEI) Polytetrafluoroethylene (PTFE) | N to N | Female Socket N Jack | N Plug Male Pin | Panel Mount | Flange | Same Series | 18 GHz | 50 Ohms | Plug to Jack | Straight |
