396-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
396 SERIES (.125" (3.18MM) CONTA
| Part | Termination Rows | Material - Insulation | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Termination | Read Out | Contact Type | Number of Positions/Bay/Row [custom] | Color | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Number of Positions [custom] | Contact Finish | Mounting Type | Card Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.156 " | 3.96 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.116 " | 2.95 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Wire Wrap | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Wire Wrap | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.128 " | 3.25 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder Wire Wrap | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Right Angle Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Wire Wrap | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder Wire Wrap | Single | Cantilever | 31 | Black | -40 C | 105 ░C | Female | 31 | Gold | Right Angle Through Hole | Non Specified - Single Edge | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening |
