OSTOQ03 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
TERM BLOCK HDR 3POS 90DEG 5.08MM
| Part | Material Flammability Rating | Housing Material | Contact Material | Insulation Height [z] | Insulation Height [z] | Mounting Type | Contact Tail Length | Contact Tail Length | Number of Levels | Voltage - UL | Operating Temperature [Min] | Operating Temperature [Max] | Type | Pitch | Pitch | Positions Per Level | Termination Style | Contact Mating Finish | Header Orientation | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | UL94 V-0 | Thermoplastic | Brass | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | 3 | Solder | Tin | 90° Right Angle | Mating Flange |
 On Shore Technology Inc. | UL94 V-0 | Thermoplastic | Brass | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | 3 | Solder | Tin | Vertical | Mating Flange |
 On Shore Technology Inc. | Thermoplastic | Brass | 3.5 mm | 0.138 " | Solder Through Hole | 0.138 in | 3.5 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 3.5 mm | 0.138 " | 3 | Solder | Tin | 90° Right Angle | ||
On Shore Technology Inc. | UL94 V-0 | Thermoplastic | Brass | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 7.62 mm | 0.3 in | 3 | Solder | Tin | 90° Right Angle | Mating Flange |
 On Shore Technology Inc. | Thermoplastic | Brass | 3.5 mm | 0.138 " | Solder Through Hole | 0.138 in | 3.5 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 3.5 mm | 0.138 " | 3 | Solder | Tin | Vertical | ||
 On Shore Technology Inc. | Thermoplastic | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -40 C | 115 °C | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | 3 | Solder | Tin | 90° Right Angle | |||
 On Shore Technology Inc. | Thermoplastic | Brass | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (2 Side) | 5.08 mm | 0.2 in | 3 | Solder | Tin | 90° Right Angle | ||
 On Shore Technology Inc. | Thermoplastic | Brass | 4 mm | 0.157 in | Solder Through Hole | 0.157 in | 4 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 5 mm | 0.197 in | 3 | Solder | Tin | Vertical | ||
 On Shore Technology Inc. | Thermoplastic | Brass | 3.5 mm | 0.138 " | Solder Through Hole | 0.138 in | 3.5 mm | 1 | 300 V | -30 ░C | 105 ░C | Header Male Pins Shrouded (4 Side) | 3.81 mm | 0.15 in | 3 | Solder | Tin | 90° Right Angle | ||
On Shore Technology Inc. | 4 mm | 0.157 in | Solder Through Hole | 1 | 300 V | -40 C | 115 °C | Header Male Pins Shrouded (4 Side) | 5.08 mm | 0.2 in | 3 | Solder | Tin | 90° Right Angle |
