TLP105 Series

Catalog

PHOTOCOUPLER

Part	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Voltage - Isolation	Supplier Device Package	Package / Case	Package / Case	Number of Channels [custom]	Rise / Fall Time (Typ)	Rise / Fall Time (Typ)	Current - Output / Channel	Inputs - Side 1/Side 2 [custom]	Voltage - Supply [Max]	Voltage - Supply [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current - DC Forward (If) (Max) [Max]	Voltage - Forward (Vf) (Typ)	Output Type	Data Rate	Input Type	Common Mode Transient Immunity (Min) [Min]
Toshiba Semiconductor and Storage TLP105(V4-TPL,F)	250 ns	250 ns	3750 Vrms	6-MFSOP 5 Lead	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1	30 ns	30 ns	25 mA	1	20 V	4.5 V	-40 C	100 °C	Surface Mount	20 mA	1.57 V	Push-Pull Totem Pole	5 MBd	DC	10 kV/µs
Toshiba Semiconductor and Storage TLP105(F)	250 ns	250 ns	3750 Vrms	6-MFSOP 5 Lead	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1	30 ns	30 ns	25 mA	1	20 V	4.5 V	-40 C	100 °C	Surface Mount	20 mA	1.57 V	Push-Pull Totem Pole	5 MBd	DC	10 kV/µs
Toshiba Semiconductor and Storage TLP105(TPL,F)	250 ns	250 ns	3750 Vrms	6-MFSOP 5 Lead	6-SOIC	0.173 " 4.4 mm Width 5 Leads	1	30 ns	30 ns	25 mA	1	20 V	4.5 V	-40 C	100 °C	Surface Mount	20 mA	1.57 V	Push-Pull Totem Pole	5 MBd	DC	10 kV/µs
