Power Line Filters 2-STAGE GP 16A FMBB
Power Line Filters 2-STAGE GP 16A FMBB
| Part | Current | Frequency - Operating [Max] | Frequency - Operating [Min] | Termination Style | Voltage - Rated AC | Filter Type | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Configuration | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 16 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
 SCHURTER Inc. | 20 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 6 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 20 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | General Purpose | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 10 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 3 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | General Purpose | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 10 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
 SCHURTER Inc. | 36 A | 60 Hz | 50 Hz | Threaded Post (M4) | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 10 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | General Purpose | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
SCHURTER Inc. | 3 A | 60 Hz | 50 Hz | Quick Connect | 125 V 250 V | Single Phase | Medical | -40 C | 100 °C | Two Stage | Chassis Mount | cURus ENEC VDE |
