VIP Series
Terminal Block Interface Modules VIP-2/SC/FLK50/PLC 32CH INTERFACE
Manufacturer: Phoenix Contact
Catalog
Terminal Block Interface Modules VIP-2/SC/FLK50/PLC 32CH INTERFACE
Beta
⌘K
Terminal Block Interface Modules VIP-2/SC/FLK50/PLC 32CH INTERFACE
Terminal Block Interface Modules VIP-2/SC/FLK50/PLC 32CH INTERFACE
Terminal Block Interface Modules VIP-2/SC/FLK50/PLC 32CH INTERFACE
| Part | Control Side Connection | Positions / Poles | Voltage - Rated | Wire Gauge [Max] | Wire Gauge [Min] | Control Side Cable Retainer | Features | Length | Length | Current Rating (Per Contact) | Operating Temperature [Min] | Operating Temperature [Max] | Width [x] | Width [x] | Process Side Connection | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Rectangular Male | 50 | 24 VDC | 24 AWG | 12 AWG | Latches | LED | 3.665 in | 93.09 mm | 1 A | -20 ░C | 50 °C | 2.717 in | 69.01 mm | Terminal Blocks - Screw Connection | ||
 Phoenix Contact | Rectangular Male (2) | 14 | 60 VDC | 24 AWG | 12 AWG | Latches | 3.173 in | 80.59 mm | 1 A | -20 ░C | 50 °C | 2.579 in | 65.5 mm | Terminal Blocks - Screw Connection | |||
 Phoenix Contact | Rectangular Male | 50 | 60 VDC | 24 AWG | 12 AWG | Latches | 1 A | -20 ░C | 50 °C | 2.579 in | 65.5 mm | Terminal Blocks - Screw Connection | 4.177 in | 106.1 mm | |||
 Phoenix Contact | Rectangular Male | 34 | 60 VDC | 24 AWG | 12 AWG | Latches | 1 A | -20 ░C | 50 °C | 2.717 in | 69.01 mm | Terminal Blocks - Screw Connection | 2.65 in | 67.31 mm |
