DKA15 Series

Catalog

DC DC CONVERTER +/-15V 15W

Part	Type	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Mounting Type	Efficiency	Applications	Voltage - Input (Max) [Max]	Number of Outputs	Voltage - Output 2	Current - Output (Max)	Package / Case	Voltage - Isolation	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Output 1	Voltage - Input (Min) [Min]	Features	Current - Output (Max) [Max]	Current - Output (Max) [Max]
MEAN WELL USA Inc. DKA15A-15	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole	83 %	ITE (Commercial)	18 V	2	-15 V	500 mA	5-DIP Module	1000 V	15 W	-40 °C	71 °C	15 V	9 V	OCP SCP
MEAN WELL USA Inc. DKA15B-12	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole	80 %	ITE (Commercial)	36 V	2	-12 V		5-DIP Module	1000 V	15 W	-40 °C	71 °C	12 V	18 V	OCP SCP	625 mA	625 mA
MEAN WELL USA Inc. DKA15C-15	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole		ITE (Commercial)	72 V	2	-15 V	500 mA	5-DIP Module	1000 V	15 W	-40 °C	71 °C	15 V	36 V	OCP SCP
MEAN WELL USA Inc. DKA15B-05	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole	80 %	ITE (Commercial)	36 V	2	-5 V	1.5 A	5-DIP Module	1000 V	15 W	-40 °C	71 °C	5 V	18 V	OCP SCP
MEAN WELL USA Inc. DKA15C-05	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole		ITE (Commercial)	72 V	2	-5 V	1.5 A	5-DIP Module	1000 V	15 W	-40 °C	71 °C	5 V	36 V	OCP SCP
MEAN WELL USA Inc. DKA15B-15	Isolated Module	2 in	0.44 in	50.8 mm	25.4 mm	1 "	11.3 mm	Through Hole	80 %	ITE (Commercial)	36 V	2	-15 V	500 mA	5-DIP Module	1000 V	15 W	-40 °C	71 °C	15 V	18 V	OCP SCP
