861400041 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN HEADER VERT 4POS 2.54MM
| Part | Current Rating (Amps) | Shrouding | Number of Positions | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Number of Rows | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Length - Post | Contact Length - Post | Number of Positions Loaded | Fastening Type | Contact Material | Contact Finish - Mating | Material Flammability Rating | Contact Type | Mounting Type | Contact Length - Mating [x] | Contact Length - Mating [x] | Connector Type | Insulation Material | Voltage Rating | Pitch - Mating | Pitch - Mating | Overall Contact Length | Overall Contact Length | Insulation Height [z] | Insulation Height [z] | Contact Length - Mating | Contact Length - Mating | Insulation Height | Insulation Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | 3 A | Unshrouded | 4 | Square | -55 °C | 125 °C | Solder | 1 | 0.203 Ám | 8 Áin | 2.84 mm | 0.112 in | All | Push-Pull | Copper Alloy | Gold or Gold GXT™ | UL94 V-0 | Male Pin | Through Hole | 0.613 in | 15.57 mm | Breakaway Header | Thermoplastic | 500 V | 0.1 in | 2.54 mm | 21.01 mm | 0.827 in | 0.102 in | 2.6 mm | ||||
Amphenol ICC (FCI) | 3 A | Unshrouded | 4 | Square | Solder | 1 | 0.203 Ám | 8 Áin | 2.84 mm | 0.112 in | All | Push-Pull | Copper Alloy | Gold or Gold GXT™ | UL94 V-0 | Male Pin | Through Hole | 0.613 in | 15.57 mm | Breakaway Header | Thermoplastic | 500 V | 0.1 in | 2.54 mm | 21.01 mm | 0.827 in | 0.102 in | 2.6 mm | ||||||
 Amphenol ICC (FCI) | 3 A | Unshrouded | 4 | Square | Solder | 1 | 4.7 mm | 0.185 in | All | Push-Pull | Copper Alloy | UL94 V-0 | Male Pin | Through Hole Right Angle | Breakaway Header | Thermoplastic | 1000 VDC | 0.1 in | 2.54 mm | 0.197 in | 5 mm | 0.1 in | 2.54 mm | |||||||||||
Amphenol ICC (FCI) | 3 A | Unshrouded | 4 | Square | -55 °C | 125 °C | Solder | 1 | 1.27 µm | 50 µin | 3 mm | 0.118 in | All | Push-Pull | Copper Alloy | Gold or Gold GXT™ | UL94 V-0 | Male Pin | Through Hole | Breakaway Header | Thermoplastic | 1000 VDC | 0.1 in | 2.54 mm | 12.6 mm | 0.496 in | 0.102 in | 2.6 mm | 0.276 in | 7 mm | ||||
Amphenol ICC (FCI) | 3 A | Unshrouded | 4 | Square | Solder | 1 | All | Push-Pull | Copper Alloy | UL94 V-0 | Male Pin | Through Hole Right Angle | Breakaway Header | Thermoplastic | 1000 VDC | 0.1 in | 2.54 mm | 0.1 in | 2.54 mm |
