SRP1206 Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 3.3UH 14A 7 MOHM SMD
| Part | Height - Seated (Max) | Height - Seated (Max) [Max] | Package / Case | Tolerance | Mounting Type | DC Resistance (DCR) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Material - Core | Current Rating (Amps) | Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Shielding | Inductance Frequency - Test | Inductance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 6 mm | 0.236 " | Nonstandard | 25 % | Surface Mount | 7 mOhm | -55 C | 150 °C | Ferrite | 14 A | Drum Core Wirewound | 12.5 mm | 0.492 " | 12.5 mm | 0.492 " | Shielded | 100 kHz | 3.3 µH |
