94HAB08 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
SWITCH ROTARY DIP OCTAL 0.1A 50V
| Part | Body Material | Length | Length | Mechanical Life | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Mounting Type | Number of Positions | Contact Finish | Voltage Rating | Features | Height Above Board [z] | Height Above Board [z] | Washable | Actuator Level | Actuator Type | Circuit | Contact Material | Termination Style | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | Plastic | 0.39 " | 9.91 mm | 10000 Steps | 85 °C | -40 C | 2.54 mm | 0.1 " | Surface Mount | 8 | Gold | 50 V | Sealed | 5.72 mm | 0.225 in | Flush Recessed | Rotary for Tool | Octal | Copper Alloy | Gull Wing | 100 mA |
