HEN.2M Series
Manufacturer: LEMO
Beta
⌘K
CONN RCPT FMALE 8POS GOLD SOLDER
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Mounting Type | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shell Material | Shielding | Features | Current Rating (Amps) | Contact Material | Applications | Mounting Feature | Color | Ingress Protection | Insert Material | Shell Size - Insert | Number of Positions | Primary Material | Fastening Type | Shell Finish | Connector Type | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LEMO | 80 °C | -20 ░C | N (Normal) | Panel Mount Through Hole | Gold | 1.5 Ám | 59 Áin | Aluminum Alloy | Shielded | Potted | 10 A | Bronze | Aerospace Automotive Aviation Military | Bulkhead - Front Side Nut | Gray | IP68 - Dust Tight Waterproof | Polyetheretherketone (PEEK) | 308 | 8 | Metal | Threaded | Nickel | Receptacle Female Sockets | Solder |
 LEMO | 80 °C | -20 ░C | N (Normal) | Panel Mount Through Hole | Gold | 1.5 Ám | 59 Áin | Aluminum Alloy | Shielded | Potted | 4 A | Bronze | Aerospace Automotive Aviation Military | Bulkhead - Front Side Nut | Gray | IP68 - Dust Tight Waterproof | Polyetheretherketone (PEEK) | 319 | 19 | Metal | Threaded | Nickel | Receptacle Female Sockets | Solder |
 LEMO | 80 °C | -20 ░C | N (Normal) | Panel Mount Through Hole | Gold | 1.5 Ám | 59 Áin | Aluminum Alloy | Shielded | Potted | 7 A | Bronze | Aerospace Automotive Aviation Military | Bulkhead - Front Side Nut | Gray | IP68 - Dust Tight Waterproof | Polyetheretherketone (PEEK) | 312 | 12 | Metal | Threaded | Nickel | Receptacle Female Sockets | Solder |
 LEMO | 80 °C | -20 ░C | N (Normal) | Panel Mount Through Hole | Gold | 1.5 Ám | 59 Áin | Aluminum Alloy | Shielded | Potted | 8 A | Bronze | Aerospace Automotive Aviation Military | Bulkhead - Front Side Nut | Gray | IP68 - Dust Tight Waterproof | Polyetheretherketone (PEEK) | 310 | 10 | Metal | Threaded | Nickel | Receptacle Female Sockets | Solder |
 LEMO | 80 °C | -20 ░C | N (Normal) | Panel Mount Through Hole | Gold | Aluminum | Shielded | Potted | Aerospace Automotive Aviation Military | Bulkhead - Front Side Nut | Gray | IP68 - Dust Tight Waterproof | Polyetheretherketone (PEEK) | 514 | 14 | Metal | Threaded | Nickel | Receptacle Female Sockets | Solder |
