Switching Power Supplies AC-DC Module, 20 Watt, Single Output, Encapsulated Type, 90-264VAC Input, 3.3VDC Output, Encapsulated
Switching Power Supplies AC-DC Module, 20 Watt, Single Output, Encapsulated Type, 90-264VAC Input, 3.3VDC Output, Encapsulated
Switching Power Supplies AC-DC Module, 20 Watt, Single Output, Encapsulated Type, 90-264VAC Input, 3.3VDC Output, Encapsulated
| Part | Number of Outputs | Features | Operating Temperature [Max] | Operating Temperature [Min] | Efficiency | Applications | Type | Approval Agency | Current - Output 1 | Mounting Type | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output 1 | Power (Watts) | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Voltage - Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 75 % | Household Appliances ITE (Commercial) | Open Frame | CE cURus TUV | 4 A | Chassis Mount | 264 VAC | 90 VAC | 3.3 V | 13 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 85 % | ITE (Commercial) Medical | Open Frame | CE cURus TUV | 900 mA | Chassis Mount | 264 VAC | 90 VAC | 24 V | 22 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
 Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 85 % | ITE (Commercial) Medical | Open Frame | CE cURus TUV | 1.7 A | Chassis Mount | 264 VAC | 90 VAC | 12 V | 20 W | 0.76 " | 40.6 mm | 1.6 in | 3 " | 19.2 mm | 76.2 mm | 4000 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 83 % | Household Appliances ITE (Commercial) | Open Frame | CE cURus TUV | 1.7 A | Chassis Mount | 264 VAC | 90 VAC | 12 V | 20 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
 Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 85 % | ITE (Commercial) Medical | Open Frame | CE cURus TUV | 1.4 A | Chassis Mount | 264 VAC | 90 VAC | 15 V | 21 W | 0.76 " | 40.6 mm | 1.6 in | 3 " | 19.2 mm | 76.2 mm | 4000 V |
 Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 88 % | Household Appliances ITE (Commercial) | Open Frame | CE cURus TUV | 900 mA | Chassis Mount | 264 VAC | 90 VAC | 24 V | 22 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 86 % | ITE (Commercial) Medical | Open Frame | CE cURus TUV | 900 mA | Chassis Mount | 264 VAC | 90 VAC | 24 V | 22 W | 0.76 " | 40.6 mm | 1.6 in | 3 " | 19.2 mm | 76.2 mm | 4000 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 83 % | Household Appliances ITE (Commercial) | Open Frame | CE cURus TUV | 1.7 A | Chassis Mount | 264 VAC | 90 VAC | 12 V | 20 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 81 % | Household Appliances ITE (Commercial) | Open Frame | CE cURus TUV | 2.3 A | Chassis Mount | 264 VAC | 90 VAC | 9 V | 21 W | 0.77 in | 40.6 mm | 1.6 in | 3 " | 19.5 mm | 76.2 mm | 5656 V |
Cincon Electronics Co. LTD | 1 | Universal Input | 70 °C | -25 °C | 83 % | ITE (Commercial) Medical | Open Frame | CE cURus TUV | 2.3 A | Chassis Mount | 264 VAC | 90 VAC | 9 V | 21 W | 0.76 " | 40.6 mm | 1.6 in | 3 " | 19.2 mm | 76.2 mm | 4000 V |
