SRU5011 Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 6.8UH 820MA 130MOHM SM
| Part | Shielding | Type | Current Rating (Amps) | Current - Saturation (Isat) | Inductance Frequency - Test | Material - Core | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Inductance | Tolerance | Package / Case | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Shielded | Drum Core Wirewound | 820 mA | 0.68 A | 100 kHz | Ferrite | 5.2 mm | 0.205 " | 0.205 " | 5.2 mm | Surface Mount | 125 °C | -40 C | 1.2 mm | 0.047 " | 6.8 µH | 30 % | Nonstandard | 130 mOhm | 7.96 MHz 8 | |
Bourns Inc. | Shielded | Drum Core Wirewound | 1.15 A | 940 mA | 100 kHz | Ferrite | 5.2 mm | 0.205 " | 0.205 " | 5.2 mm | Surface Mount | 125 °C | -40 C | 1.2 mm | 0.047 " | 3.3 µH | 30 % | Nonstandard | 66 mOhm | 7.96 MHz 8 | 110 MHz |
Bourns Inc. | Shielded | Drum Core Wirewound | 1.3 A | 1.1 A | 100 kHz | Ferrite | 5.2 mm | 0.205 " | 0.205 " | 5.2 mm | Surface Mount | 125 °C | -40 C | 1.2 mm | 0.047 " | 2.5 µH | 30 % | Nonstandard | 52 mOhm | 7.96 MHz 8 | 125 MHz |
