Sitara processor: Arm Cortex-A8, 3D graphics, camera
Key Features
• AM3715, AM3703 Sitara ARM Microprocessors:Compatible to OMAP™ 3 ArchitectureMPU SubsystemUp to 1-GHz Sitara™ ARM® Cortex™-A8 Core Also supports 300, 600, and 800-MHz operationNEON SIMD CoprocessorPOWERVR SGX™ Graphics Accelerator (AM3715 only)Tile Based Architecture Delivering up to 20 MPoly/secUniversal Scalable Shader Engine: Multi-threaded Engine Incorporating Pixel and Vertex Shader FunctionalityIndustry Standard API Support: OpenGLES 1.1 and 2.0, OpenVG1.0Fine Grained Task Switching, Load Balancing, and Power ManagementProgrammable High Quality Image Anti-AliasingExternal Memory Interfaces:SDRAM Controller (SDRC)16, 32-bit Memory Controller With 1G-Byte Total Address SpaceInterfaces to Low-Power SDRAMSDRAM Memory Scheduler (SMS) and Rotation EngineGeneral Purpose Memory Controller (GPMC)16-bit Wide Multiplexed Address/Data BusUp to 8 Chip Select Pins With 128M-Byte Address Space per Chip Select PinGlueless Interface to NOR Flash, NAND Flash (With ECC Hamming Code Calculation), SRAM and Pseudo-SRAMFlexible Asynchronous Protocol Control for Interface to Custom Logic (FPGA, CPLD, ASICs, etc.)Nonmultiplexed Address/Data Mode (Limited 2K-Byte Address Space)POWERVR SGX is a trademark of Imagination Technologies Ltd.OMAP is a trademark of Texas Instruments.All other trademarks are the property of their respective owners.AM3715, AM3703 Sitara ARM Microprocessors:Compatible to OMAP™ 3 ArchitectureMPU SubsystemUp to 1-GHz Sitara™ ARM® Cortex™-A8 Core Also supports 300, 600, and 800-MHz operationNEON SIMD CoprocessorPOWERVR SGX™ Graphics Accelerator (AM3715 only)Tile Based Architecture Delivering up to 20 MPoly/secUniversal Scalable Shader Engine: Multi-threaded Engine Incorporating Pixel and Vertex Shader FunctionalityIndustry Standard API Support: OpenGLES 1.1 and 2.0, OpenVG1.0Fine Grained Task Switching, Load Balancing, and Power ManagementProgrammable High Quality Image Anti-AliasingExternal Memory Interfaces:SDRAM Controller (SDRC)16, 32-bit Memory Controller With 1G-Byte Total Address SpaceInterfaces to Low-Power SDRAMSDRAM Memory Scheduler (SMS) and Rotation EngineGeneral Purpose Memory Controller (GPMC)16-bit Wide Multiplexed Address/Data BusUp to 8 Chip Select Pins With 128M-Byte Address Space per Chip Select PinGlueless Interface to NOR Flash, NAND Flash (With ECC Hamming Code Calculation), SRAM and Pseudo-SRAMFlexible Asynchronous Protocol Control for Interface to Custom Logic (FPGA, CPLD, ASICs, etc.)Nonmultiplexed Address/Data Mode (Limited 2K-Byte Address Space)POWERVR SGX is a trademark of Imagination Technologies Ltd.OMAP is a trademark of Texas Instruments.All other trademarks are the property of their respective owners.
Description
AI
The AM37x generation (AM3715/AM3703) of Sitara™ high-performance microprocessors is based on the enhanced Cortex™-A8 device architecture and is integrated on TI's advanced 45-nm process technology. This architecture is designed to provide best in class ARM and graphics performance while delivering low power consumption.
The device can support numerous high-level operating systems and real-time operating system solutions including Linux, Android and Windows Embedded CE which are available free of charge directly from TI. Additionally, the device is fully backward compatible with previous Cortex-A8 Sitara microprocessors and OMAP™ processors.
The AM3715/AM3703 microprocessor data manual presents the electrical and mechanical specifications for the AM3715/AM3703 microprocessor.
The information contained in this data manual applies to both the commercial and extended temperature versions of the AM3715/03 Microprocessor unless otherwise indicated. It consists of the following sections:
The AM37x generation (AM3715/AM3703) of Sitara™ high-performance microprocessors is based on the enhanced Cortex™-A8 device architecture and is integrated on TI's advanced 45-nm process technology. This architecture is designed to provide best in class ARM and graphics performance while delivering low power consumption.
The device can support numerous high-level operating systems and real-time operating system solutions including Linux, Android and Windows Embedded CE which are available free of charge directly from TI. Additionally, the device is fully backward compatible with previous Cortex-A8 Sitara microprocessors and OMAP™ processors.
The AM3715/AM3703 microprocessor data manual presents the electrical and mechanical specifications for the AM3715/AM3703 microprocessor.
The information contained in this data manual applies to both the commercial and extended temperature versions of the AM3715/03 Microprocessor unless otherwise indicated. It consists of the following sections:
