BAV23 Series
Manufacturer: Diotec Semiconductor
Beta
⌘K
IC
| Part | Current - Average Rectified (Io) (per Diode) | Reverse Recovery Time (trr) | Speed | Voltage - Forward (Vf) (Max) @ If | Voltage - DC Reverse (Vr) (Max) [Max] | Mounting Type | Supplier Device Package | Technology | Package / Case | Diode Configuration | Current - Reverse Leakage @ Vr | Operating Temperature - Junction [Min] | Operating Temperature - Junction [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Diotec Semiconductor | 225 mA | 50 ns | 200 mA 500 ns | 1.25 V | 200 V | Surface Mount | SOT-23-3 (TO-236) | Standard | SC-59 SOT-23-3 TO-236-3 | 1 Pair Common Cathode | 100 nA | -55 °C | 150 °C |
Diotec Semiconductor | 225 mA | 50 ns | 200 mA 500 ns | 1.25 V | 200 V | Surface Mount | SOT-23-3 (TO-236) | Standard | SC-59 SOT-23-3 TO-236-3 | 1 Pair Series Connection | 100 nA | -55 °C | 150 °C |
