L77SDE09 Series
Manufacturer: Amphenol ICC (Commercial Products)
Beta
⌘K
CONN D-SUB RCPT 9POS R/A SLDR
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Contact Form | Voltage Rating | Mounting Type | Termination | Flange Feature | Material Flammability Rating | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Features | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Backset Spacing | Backset Spacing | Number of Rows [custom] | Connector Type | Current Rating (Amps) | Connector Style | Contact Finish | Contact Finish Thickness | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | 4-40 Mating Side Female Screwlock | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | Board Lock | 9 | 1 | DE E | 8.08 mm | 0.318 " | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | ||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | Board Side (4-40) | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | Board Lock | 9 | 1 | DE E | 14.99 mm | 0.59 in | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | ||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | 4-40 Mating Side Female Screwlock | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | Board Lock | 9 | 1 | DE E | 8.08 mm | 0.318 " | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | ||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Through Hole | Solder | Housing/Shell (Unthreaded) | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | 9 | 1 | DE E | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | |||||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | 4-40 Mating Side Female Screwlock | UL94 V-0 | Signal | Board Lock | 9 | 1 | DE E | 8.08 mm | 0.318 " | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | Flash | |||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | Board Side (4-40) | UL94 V-0 | Signal | Board Lock | 9 | 1 | DE E | 8.08 mm | 0.318 " | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | Flash | |||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | Board Side (4-40) | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | Board Lock | 9 | 1 | DE E | 10.3 mm | 0.406 in | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | ||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | 4-40 Mating Side Female Screwlock | UL94 V-0 | Signal | Board Lock | 9 | 1 | DE E | 8.08 mm | 0.318 " | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | Flash | |||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 105 ░C | Brass | Stamped | 250 V | Free Hanging (In-Line) | Housing/Shell (Unthreaded) | UL94 V-0 | Signal | 9 | 1 | DE E | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold | Flash | 20 AWG | ||||||
 Amphenol ICC (Commercial Products) | Black | Thermoplastic Glass Filled | -55 C | 125 °C | Phosphor Bronze | Stamped | 250 V | Right Angle Through Hole | Solder | Board Side (4-40) | UL94 V-0 | Signal | 30 Áin | 0.76 Ám | Board Lock | 9 | 1 | DE E | 2 | Receptacle Female Sockets | 3 A | D-Sub | Gold |
