ERJ-S1 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
RES 866 OHM 1% 1W 2512
| Part | Ratings | Power (Watts) | Temperature Coefficient | Supplier Device Package | Features | Number of Terminations | Resistance | Operating Temperature [Max] | Operating Temperature [Min] | Tolerance | Composition | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Package / Case | Package / Case | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Power (Watts) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | AEC-Q200 | 1 W | 100 ppm/°C | 2512 | Anti-Sulfur Automotive AEC-Q200 | 2 | 866 Ohms | 155 °C | -55 °C | 1 % | Thick Film | 0.7 mm | 0.028 in | 6432 Metric | 2512 | |||||
 Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 200 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 820 Ohms | 155 °C | -55 °C | 5 % | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | |
Panasonic Industrial Automation Sales | AEC-Q200 | 1 W | 100 ppm/°C | 2512 | Anti-Sulfur Automotive AEC-Q200 | 2 | 130 kOhms | 155 °C | -55 °C | Thick Film | 0.7 mm | 0.028 in | 6432 Metric | 2512 | ||||||
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 100 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 91 Ohms | 155 °C | -55 °C | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | ||
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 100 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 54.9 kOhms | 155 °C | -55 °C | 1 % | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | |
 Panasonic Industrial Automation Sales | AEC-Q200 | 1 W | 100 ppm/°C | 2512 | Anti-Sulfur Automotive AEC-Q200 | 2 | 267 Ohms | 155 °C | -55 °C | Thick Film | 0.7 mm | 0.028 in | 6432 Metric | 2512 | ||||||
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 100 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 2.26 kOhms | 155 °C | -55 °C | 1 % | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | |
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 200 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 155 °C | -55 °C | 5 % | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | ||
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 100 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 332 kOhms | 155 °C | -55 °C | 1 % | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W | |
Panasonic Industrial Automation Sales | AEC-Q200 | 0.75 W | 100 ppm/°C | 2010 | Anti-Sulfur Automotive AEC-Q200 | 2 | 51 kOhms | 155 °C | -55 °C | Thick Film | 0.7 mm | 0.028 in | 2010 (5025 Metric) | 0.197 in | 0.098 in | 5 mm | 2.5 mm | 0.75 W |
