857-042 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FML 42POS 0.156
| Part | Number of Positions | Read Out | Contact Finish | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows | Number of Rows | Contact Material | Card Type | Material - Insulation | Number of Positions/Bay/Row | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Color | Flange Feature | Contact Type | Termination | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Number of Positions [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Features | Number of Positions/Bay/Row [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 42 | Single | Tin | Female | 125 °C | -40 C | 1 | 1 | Copper Alloy | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | Solder | Right Angle Through Hole | |||||||||
EDAC Inc. | Dual | Gold | Female | 125 °C | -40 C | 1 | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Flush Mount Top Opening Unthreaded | Semi Bellows | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 2 | 84 | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | Dual | Gold | Female | 125 °C | -40 C | 1 | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | Wire Wrap | Through Hole | 0.25 Ám | 10 Áin | 2 | 84 | |||||||
 EDAC Inc. | 42 | Single | Gold | Female | 125 °C | -40 C | 1 | 1 | Copper Alloy | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Flush Mount Top Opening Unthreaded | Semi Bellows | Solder | Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |||||
 EDAC Inc. | 42 | Single | Gold | Female | 125 °C | -40 C | 1 | 1 | Copper Alloy | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Floating Bobbin Flush Mount | Semi Bellows | Solder Eyelet(s) | Through Hole | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | |||||
 EDAC Inc. | 42 | Dual | Tin | Female | 125 °C | -40 C | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | Solder | Board Edge Straddle Mount | 2 | 2 | Card Extender | 21 | ||||||||
 EDAC Inc. | 42 | Single | Tin | Female | 125 °C | -40 C | 1 | 1 | Copper Alloy | Non Specified - Single Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Semi Bellows | Solder | Through Hole | ||||||||||
 EDAC Inc. | Dual | Gold | Female | 125 °C | -40 C | 1 | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 42 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Floating Bobbin Flush Mount | Semi Bellows | Solder | Right Angle Through Hole | 0.25 Ám | 10 Áin | 2 | 84 | 0.116 " | 2.95 mm | |||||
 EDAC Inc. | 42 | Dual | Tin | Female | 125 °C | -40 C | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Floating Bobbin Flush Mount | Semi Bellows | Wire Wrap | Through Hole | 2 | 0.116 " | 2.95 mm | 2 | 21 | |||||||
 EDAC Inc. | 42 | Dual | Gold | Female | 125 °C | -40 C | Copper Alloy | Non Specified - Dual Edge | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | Semi Bellows | Solder | Through Hole | 0.25 Ám | 10 Áin | 2 | 2 | 21 |
