TPSI3052 Series

Isolated switch driver with integrated 15-V gate supply

Catalog

Isolated switch driver with integrated 15-V gate supply

Part	Current - Peak Output	Supplier Device Package	Approval Agency	Current - DC Forward (If) (Max) [Max]	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Voltage - Output Supply [Max]	Voltage - Output Supply [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Common Mode Transient Immunity (Min) [Min]	Number of Channels	Mounting Type	Technology	Package / Case	Package / Case [custom]	Package / Case [custom]	Voltage - Isolation
Texas Instruments TPSI3052DWZR	1.5 A 3 A	8-SOIC	UL VDE	37 mA	3 A	1.5 A	5.5 V	3 V	125 °C	-40 °C	100 V/ns	1	Surface Mount	Capacitive Coupling	8-SOIC	0.295 in	7.5 mm	3000 VAC
Texas Instruments TPSI3052SDWZR	1.5 A 3 A	8-SOIC	UL VDE	37 mA	3 A	1.5 A	5.5 V	3 V	125 °C	-40 °C	100 V/ns	1	Surface Mount	Capacitive Coupling	8-SOIC	0.295 in	7.5 mm	3000 VAC

Catalog

Isolated switch driver with integrated 15-V gate supply

Key Features

• No isolated secondary supply requiredDrives external power transistors or SCRs3-kV RMS basic isolation15-V gate drive with 1.5/3-A peak source and sink currentUp to 50-mW supply for external auxiliary circuitrySupports AC or DC switchingSupports two-wire or three-wire modesSeven levels of power transfer, resistor selectableFunctional Safety-CapableDocumentation available to aid functional safety system designTemperature range –40 to 125°C ambientSafety-Related Certifications4243-V PK basic isolation per DIN EN IEC 60747-17 (VDE 0884-17)3-kV RMS isolation for 1 minute per UL 1577No isolated secondary supply requiredDrives external power transistors or SCRs3-kV RMS basic isolation15-V gate drive with 1.5/3-A peak source and sink currentUp to 50-mW supply for external auxiliary circuitrySupports AC or DC switchingSupports two-wire or three-wire modesSeven levels of power transfer, resistor selectableFunctional Safety-CapableDocumentation available to aid functional safety system designTemperature range –40 to 125°C ambientSafety-Related Certifications4243-V PK basic isolation per DIN EN IEC 60747-17 (VDE 0884-17)3-kV RMS isolation for 1 minute per UL 1577

Description

The TPSI3052 is a fully integrated, isolated switch driver, which when combined with an external power switch, forms a complete isolated solid state relay (SSR). With a nominal gate drive voltage of 15 V with 1.5/3.0-A peak source and sink current, a large variety of external power switches can be chosen to meet a wide range of applications. The TPSI3052 generates its own secondary bias supply from the power received from its primary side, so no isolated secondary supply bias is required. Additionally, the TPSI3052 can optionally supply power to external supporting circuitry for various application needs. The TPSI3052 supports two modes of operation based on the number of input pins required. In two-wire mode, typically found in driving mechanical relays, controlling the switch requires only two pins and supports a wide voltage range of operation of 6.5 V to 48 V. In three-wire mode, the primary supply of 3 V to 5.5 V is supplied externally, and the switch is controlled through a separate enable. Available in three-wire mode only, the TPSI3052S features a one-shot enable for the switch control. This feature is useful for driving SCRs that typically require only one pulse of current to trigger. The secondary side provides a regulated, floating supply rail of 15 V for driving a large variety of power switches with no need for a secondary bias supply. The application can drive single power switches for DC applications or dual back-to-back power switches for AC applications, as well as various types of SCR. The TPSI3052 integrated isolation protection is extremely robust with much higher reliability, lower power consumption, and increased temperature ranges than traditional mechanical relays and optocouplers. The power transfer of the TPSI3052 can be adjusted by selecting one of seven power level settings using an external resistor from the PXFR pin to VSSP. This action allows for tradeoffs in power dissipation versus power provided on the secondary depending on the needs of the application. The TPSI3052 is a fully integrated, isolated switch driver, which when combined with an external power switch, forms a complete isolated solid state relay (SSR). With a nominal gate drive voltage of 15 V with 1.5/3.0-A peak source and sink current, a large variety of external power switches can be chosen to meet a wide range of applications. The TPSI3052 generates its own secondary bias supply from the power received from its primary side, so no isolated secondary supply bias is required. Additionally, the TPSI3052 can optionally supply power to external supporting circuitry for various application needs. The TPSI3052 supports two modes of operation based on the number of input pins required. In two-wire mode, typically found in driving mechanical relays, controlling the switch requires only two pins and supports a wide voltage range of operation of 6.5 V to 48 V. In three-wire mode, the primary supply of 3 V to 5.5 V is supplied externally, and the switch is controlled through a separate enable. Available in three-wire mode only, the TPSI3052S features a one-shot enable for the switch control. This feature is useful for driving SCRs that typically require only one pulse of current to trigger. The secondary side provides a regulated, floating supply rail of 15 V for driving a large variety of power switches with no need for a secondary bias supply. The application can drive single power switches for DC applications or dual back-to-back power switches for AC applications, as well as various types of SCR. The TPSI3052 integrated isolation protection is extremely robust with much higher reliability, lower power consumption, and increased temperature ranges than traditional mechanical relays and optocouplers. The power transfer of the TPSI3052 can be adjusted by selecting one of seven power level settings using an external resistor from the PXFR pin to VSSP. This action allows for tradeoffs in power dissipation versus power provided on the secondary depending on the needs of the application.
