1.5SMC Series

Catalog

SURFACE MOUNT TRANSIENT VOLTAGE

...

Part	Type	Applications	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Clamping (Max) @ Ipp [Max]	Voltage - Reverse Standoff (Typ)	Supplier Device Package	Power - Peak Pulse	Power - Peak Pulse	Unidirectional Channels [custom]	Voltage - Breakdown (Min) [Min]	Package / Case	Mounting Type	Current - Peak Pulse (10/1000µs)	Bidirectional Channels [custom]	Qualification	Grade
Panjit International Inc. 1.5SMCJ10A_R1_00001	Zener	General Purpose	150 °C	-55 °C	17 V	10 V	DO-214AB (SMC)	1.5 kW	1500 W	1	11.1 V	DO-214AB SMC	Surface Mount	88.2 A
Panjit International Inc. 1.5SMC36A_R1_00001	Zener	General Purpose	150 °C	-55 °C	49.9 V	30.8 V	DO-214AB (SMC)	1.5 kW	1500 W	1	34.2 V	DO-214AB SMC	Surface Mount	30 A
Panjit International Inc. 1.5SMCJ170CA_R1_00001	Zener	General Purpose	150 °C	-55 °C	275 V	170 V	DO-214AB (SMC)	1.5 kW	1500 W		189 V	DO-214AB SMC	Surface Mount	5.5 A	1
Panjit International Inc. 1.5SMC120AS_R1_00001	Zener	General Purpose	150 °C	-55 °C	165 V	102 V	DO-214AB (SMC)	1.5 kW	1500 W	1	114 V	DO-214AB SMC	Surface Mount	9.1 A
Panjit International Inc. 1.5SMCJ90A_R1_00001	Zener	General Purpose	150 °C	-55 °C	146 V	90 V	DO-214AB (SMC)	1.5 kW	1500 W	1	100 V	DO-214AB SMC	Surface Mount	10.3 A
Panjit International Inc. 1.5SMCJ6.0CA_R1_00001	Zener	General Purpose	150 °C	-55 °C	10.3 V	6 V	DO-214AB (SMC)	1.5 kW	1500 W		6.67 V	DO-214AB SMC	Surface Mount	145.6 A	1
Panjit International Inc. 1.5SMCJ40AS_R1_00001	Zener	General Purpose	150 °C	-55 °C	64.5 V	40 V	DO-214AB (SMC)	1.5 kW	1500 W	1	44.4 V	DO-214AB SMC	Surface Mount	23.2 A
Panjit International Inc. 1.5SMC13A-AU_R1_000A1	Zener		150 °C	-55 °C	18.2 V	11.1 V	DO-214AB (SMC)	1.5 kW	1500 W	1	12.4 V	DO-214AB SMC	Surface Mount	82 A		AEC-Q101	Automotive
Panjit International Inc. 1.5SMCJ45CA_R1_00001	Zener	General Purpose	150 °C	-55 °C	72.7 V	45 V	DO-214AB (SMC)	1.5 kW	1500 W		50 V	DO-214AB SMC	Surface Mount	20.6 A	1
Panjit International Inc. 1.5SMCJ51CA_R1_00001	Zener	General Purpose	150 °C	-55 °C	82.4 V	51 V	DO-214AB (SMC)	1.5 kW	1500 W			DO-214AB SMC	Surface Mount	18.2 A	1
