3403.0270 Series
Manufacturer: SCHURTER Inc.
Beta
⌘K
FUSE BRD MNT 400MA 277VAC 250VDC
| Part | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - AC | Breaking Capacity @ Rated Voltage | Approval Agency | Response Time | Current Rating (Amps) | Voltage Rating - DC | Mounting Type | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Melting I²t | Fuse Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SCHURTER Inc. | 2-SMD Square End Block | -55 C | 125 °C | 277 V | 1.5 kA | CQC cURus VDE | Slow Blow | 400 mA | 250 V | Surface Mount | 0.211 in | 0.606 in | 0.211 " | 15.4 mm | 5.35 mm | 5.35 mm | 0.33 | Board Mount (Cartridge Style Excluded) |
