892-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 28POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Number of Positions | Gender | Read Out | Number of Positions/Bay/Row | Contact Material | Contact Finish | Mounting Type | Pitch | Pitch | Color | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Termination | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 28 | Female | Single | 28 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | Solder | Cantilever | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 28 | Female | Single | 28 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Solder | Cantilever | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 28 | Female | Single | 28 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | Solder Eyelet(s) | Cantilever | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Copper Alloy | Gold | Board Edge Straddle Mount | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Solder | Cantilever | 0.25 Ám | 10 Áin | 2 | 2 | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Solder Eyelet(s) | Cantilever | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Copper Alloy | Gold | Right Angle Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Cantilever | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 28 | Female | Single | 28 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 1 | Solder | Cantilever | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Solder | Cantilever | 0.25 Ám | 10 Áin | 2 | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | 28 | Female | Single | 28 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Solder Eyelet(s) | Cantilever | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | 28 | Female | Dual | 14 | Copper Alloy | Gold | Through Hole | 0.1 " | 2.54 mm | Black | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Wire Wrap | Cantilever | 0.25 Ám | 10 Áin | 2 | 2 |
