147382 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER SMD 30POS 1.27MM
| Part | Number of Rows | Row Spacing - Mating | Row Spacing - Mating | Pitch - Mating | Pitch - Mating | Contact Length - Mating | Contact Length - Mating | Insulation Material | Contact Type | Contact Shape | Features | Contact Material | Mated Stacking Heights | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Insulation Color | Contact Finish - Mating | Contact Finish - Post | Mounting Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Positions Loaded | Fastening Type | Termination | Applications | Connector Type | Insulation Height | Insulation Height | Number of Positions | Shrouding | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 2 | 0.05 in | 1.27 mm | 0.05 in | 1.27 mm | 3.05 mm | 0.12 in | Liquid Crystal Polymer (LCP) | Male Pin | Circular | Board Lock Pick and Place | Phosphor Bronze | 8.13 mm | -65 ░C | 105 ░C | 500 mA | Black | Gold | Tin | Surface Mount | 150 Áin | 3.81 Ám | All | Push-Pull | Solder | Automotive General Purpose Medical Military Telecommunications | Header | 0.298 in | 7.57 mm | 30 | Shrouded - 4 Wall | 30 Áin | 0.76 Ám | UL94 V-0 |
 TE Connectivity Raychem Cable Protection | 2 | 0.05 in | 1.27 mm | 0.05 in | 1.27 mm | 3.05 mm | 0.12 in | Liquid Crystal Polymer (LCP) | Male Pin | Circular | Board Lock Pick and Place | Phosphor Bronze | 8.13 mm | -65 ░C | 105 ░C | 500 mA | Black | Gold | Tin | Surface Mount | 150 Áin | 3.81 Ám | All | Push-Pull | Solder | Automotive General Purpose Medical Military Telecommunications | Header | 0.298 in | 7.57 mm | 10 | Shrouded - 4 Wall | 30 Áin | 0.76 Ám | UL94 V-0 |
TE Connectivity Raychem Cable Protection | 2 | 0.05 in | 1.27 mm | 0.05 in | 1.27 mm | 3.05 mm | 0.12 in | Liquid Crystal Polymer (LCP) | Male Pin | Circular | Board Lock Pick and Place | Phosphor Bronze | 8.13 mm | -65 ░C | 105 ░C | 500 mA | Black | Gold | Tin-Lead | Surface Mount | 150 Áin | 3.81 Ám | All | Push-Pull | Solder | Automotive General Purpose Medical Military Telecommunications | Header | 0.298 in | 7.57 mm | 10 | Shrouded - 4 Wall | 30 Áin | 0.76 Ám | UL94 V-0 |
