181-015 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB HD PLUG 15P R/A SLDR
| Part | Contact Material | Color | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Material Flammability Rating | Current Rating (Amps) | Number of Positions | Mounting Type | Connector Style | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Features | Termination | Number of Rows [custom] | Flange Feature | Contact Type | Backset Spacing | Backset Spacing | Connector Type | Contact Finish | Voltage Rating | Shell Material, Finish | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | Black | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | 2 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Board Lock Grounding Indents | Solder | 3 | 4-40 Mating Side Female Screwlock | Signal | 8.89 mm | 0.35 in | Plug Male Pins | Gold | |||
NorComp Inc. | Brass | Black | 105 ░C | -55 C | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 3 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Ground Strap Shielded | Solder | 3 | Housing/Shell (Unthreaded) | Signal | 8.89 mm | 0.35 in | Receptacle Female Sockets | Gold | 250 V | Nickel Plated Steel | |
 NorComp Inc. | Brass | Black | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | 2 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Ground Strap | Solder | 3 | Housing/Shell | Signal | 8.89 mm | 0.35 in | Receptacle Female Sockets | Gold | 4-40 | ||
 NorComp Inc. | Brass | Black | 105 ░C | -55 C | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 3 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Board Lock Shielded | Solder | 3 | 4-40 Mating Side Female Screwlock | Signal | 8.89 mm | 0.35 in | Receptacle Female Sockets | Gold | 250 V | Nickel Plated Steel | |
NorComp Inc. | Brass | Black | 105 ░C | -55 C | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 3 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Board Lock Grounding Indents Shielded | Solder | 3 | 4-40 Mating Side Female Screwlock | Signal | 8.89 mm | 0.35 in | Plug Male Pins | Gold | 250 V | Nickel Plated Steel | |
 NorComp Inc. | Brass | Black | 105 ░C | -55 C | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 3 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Board Lock Grounding Indents Shielded | Solder | 3 | Housing/Shell | Signal | 8.89 mm | 0.35 in | Plug Male Pins | Gold | 250 V | Nickel Plated Steel | 4-40 |
NorComp Inc. | Brass | Black | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | UL94 V-0 | 2 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Ground Strap Grounding Indents | Solder | 3 | Housing/Shell | Signal | 8.89 mm | 0.35 in | Plug Male Pins | Gold | 4-40 | ||
NorComp Inc. | Brass | Black | 105 ░C | -55 C | Nylon 9T Polyamide (PA9T) | UL94 V-0 | 3 A | 15 | Panel Mount Right Angle Through Hole | D-Sub High Density | Flash | (DE E) High Density | 1 | Ground Strap Shielded | Solder | 3 | Housing/Shell | Signal | 8.89 mm | 0.35 in | Receptacle Female Sockets | Gold | 250 V | Nickel Plated Steel | 4-40 |
