6410 Series
KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
Manufacturer: Molex
Catalog
KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
Beta
⌘K
KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
KK 254 Wire-to-Board Header, Vertical, with Friction Lock, 4 Circuits, Tin (Sn) Plating
| Part | Insulation Material | Number of Positions | Contact Shape | Contact Type | Insulation Color | Insulation Height | Insulation Height | Number of Positions Loaded | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Mounting Type | Fastening Type | Overall Contact Length | Overall Contact Length | Style | Contact Material | Connector Type | Material Flammability Rating | Pitch - Mating | Pitch - Mating | Contact Length - Mating | Contact Length - Mating | Termination | Contact Length - Post | Contact Length - Post | Number of Rows | Shrouding | Contact Finish - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Nylon Polyamide (PA) | 13 | Square | Male Pin | Natural | 0.461 in | 11.7 mm | All | 100 çin | 2.54 çm | Through Hole | Friction Lock | 0.56 in | 14.22 mm | Board to Cable/Wire | Brass | Header | UL94 V-0 | 0.1 " | 2.54 mm | 7.49 mm | 0.295 in | Solder | 3.56 mm | 0.14 in | 1 | Shrouded - 1 Wall | Tin |
 Molex | Nylon Polyamide (PA) | 7 | Square | Male Pin | Natural | 0.461 in | 11.7 mm | All | 100 çin | 2.54 çm | Through Hole | Friction Lock | 0.56 in | 14.22 mm | Board to Cable/Wire | Brass | Header | UL94 V-0 | 0.1 " | 2.54 mm | 7.49 mm | 0.295 in | Solder | 3.56 mm | 0.14 in | 1 | Shrouded - 1 Wall | Tin |
