GRSE18S Series

Catalog

SENSOR THROUGH-BEAM 15M PNP

Part	Output Configuration	Cable Length	Cable Length	Ingress Protection	Voltage - Supply [Min]	Voltage - Supply [Max]	Sensing Method	Sensing Distance	Sensing Distance	Connection Method	Response Time	Operating Temperature [Min]	Operating Temperature [Max]	Light Source	Sensing Distance	Adjustment Type
SICK, Inc. 1062422	PNP	78.74 "	2 m	IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Cable	500 µs	-25 °C	55 °C	RED (650nm)
SICK, Inc. 1069626	PNP	78.74 "	2 m	IP67	10 VDC	30 VDC	Through-Beam		393.701 in	Cable	500 µs	-25 °C	55 °C	RED (650nm)	10 m	Adjustable Potentiometer
SICK, Inc. 1062122	NPN	78.74 "	2 m	IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Cable	500 µs	-25 °C	55 °C	RED (650nm)
SICK, Inc. 1069637	PNP	78.74 "	2 m	IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Cable	500 µs	-25 °C	55 °C	Infrared (880nm)		Adjustable Potentiometer
SICK, Inc. 1069627	PNP			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	RED (650nm)		Adjustable Potentiometer
SICK, Inc. 1069125	PNP			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	RED (650nm)		Adjustable Potentiometer
SICK, Inc. 1069636	PNP			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	Infrared (880nm)		Adjustable Potentiometer
SICK, Inc. GRSE18S-N2422	NPN			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	Infrared (880nm)		Adjustable Potentiometer
SICK, Inc. 1059550	PNP			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	RED (650nm)
SICK, Inc. 1059551	PNP			IP67	10 VDC	30 VDC	Through-Beam	590.551 in	15 m	Connector M12	500 µs	-25 °C	55 °C	RED (650nm)
