TSPD11 Series

Catalog

PUSHBUTTON SWITCHES SPST OFF-(ON) R/A SMT PB SWITCH

Part	Electrical Life	Operating Temperature [Max]	Operating Temperature [Min]	Termination Style	Actuator Marking	Voltage Rating - DC	Features	Mounting Type	Voltage Rating - AC	Color - Actuator/Cap	Circuit	Type	Actuator Type	Current Rating (Amps)	Switch Function
TE Connectivity AMP Connectors TSPD11CGSRA0	80000 Cycles	85 °C	-30 ░C	Gull Wing	No Marking	20 V	Process Sealed	Right Angle Surface Mount	20 V	Black	SPST-NO	Standard	Plunger Round	0.4 VA	Off-Mom
TE Connectivity AMP Connectors TSPD11FGRA0	60000 Cycles	85 °C	-30 ░C	PC Pin	No Marking	20 V	Process Sealed	Right Angle Through Hole	20 V	Black	SPDT	Standard	Plunger Round	0.4 VA	On-Mom
TE Connectivity AMP Connectors TSPD11CGRA2	80000 Cycles	85 °C	-30 ░C	PC Pin	No Marking	20 V	Process Sealed	Right Angle Through Hole	20 V	Red	SPST-NO	Standard	Plunger Round	0.4 VA	Off-Mom
TE Connectivity AMP Connectors TSPD11CGSPC0	80000 Cycles	85 °C	-30 ░C	Gull Wing	No Marking	20 V	Process Sealed	Surface Mount	20 V	Black	SPST-NO	Standard	Plunger Round	0.4 VA	Off-Mom
