WA-2R-A Series

Catalog

SWITCH SNAP ACT SPST-NC 20A 125V

Part	Mechanical Life	Mounting Type	Actuator Type	Switch Function	Circuit	Pretravel	Pretravel	Operating Force [Max]	Operating Force [Min]	Termination Style	Current Rating (Amps)	Differential Travel	Differential Travel	Overtravel [custom]	Overtravel [custom]	Voltage Rating - AC	Voltage Rating - DC	Operating Position [x]	Operating Position [x]	Operating Temperature [Min]	Operating Temperature [Max]	Release Force
Honeywell Sensing and Productivity Solutions WA-2R-A2	20000000 Cycles	Chassis Mount	Round (Pin Plunger)	On-Mom	SPST-NC	0.05 in	1.27 mm	624 gf	397 gf	Screw Terminal	20 A 500 mA	0.007 in	0.18 mm	0.01 "	0.25 mm	125 V	125 VDC	16.3 mm	0.64 in	-55 C	85 °C	283 gf
Honeywell Sensing and Productivity Solutions WA-2R-A21	20000000 Cycles	Chassis Mount	Round (Pin Plunger)	On-Mom	SPST-NC	0.05 in	1.27 mm	624 gf	397 gf	Screw Terminal	20 A	0.007 in	0.18 mm	0.01 "	0.25 mm	125 V		16.3 mm	0.64 in	-55 C	85 °C	283 gf
