AAD1-9090 Series

Catalog

LED MOD XPOWER RGB STARBOARD

Part	Type	Color	Current - Max [Max]	Wavelength [custom]	Wavelength [custom]	Wavelength [custom]	Viewing Angle	Height [z]	Voltage - Forward (Vf) (Typ)	Current - Test	Lens Type	Configuration	Size / Dimension [y]	Size / Dimension [x]	Lumens/Watt @ Current - Test	Wavelength	Temperature - Test	Luminous Flux @ Current/Temperature	Thermal Resistance of Package	Package / Case	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max)	Luminous Flux @ Current/Temperature [custom]	Luminous Flux @ Current/Temperature [custom]	Luminous Flux @ Current/Temperature [custom]	Current - Max [custom]	Current - Max [custom]	Current - Max [custom]
Kingbright AAD1-9090BRGC-01/3-S	LED Module	Blue Green Red	350 mA	530 nm	625 nm	458 nm	135 °	8.3 mm	2.5 V 3.2 V 3.3 V	350 mA	Domed	Starboard	19.05 mm	19.75 mm
Kingbright AAD1-9090QB11ZC/3-S	LED Module	Blue	700 mA				135 °	8.3 mm	3.9 V		Domed	Starboard	19.05 mm	19.75 mm	7 lm/W	460 nm	25 °C	20 lm
Kingbright AAD1-9090QB11ZC/3		Blue	700 mA				100 °		3.9 V				0.354 in	0.354 in	11 lm/W	460 nm	25 °C	29 lm	11 °C/W	2-SMD Gull Wing Exposed Pad	9 mm	9 mm	Surface Mount	0.267 in	6.78 mm
Kingbright AAD1-9090SE28ZC-S	LED Module	Orange-Red	350 mA				135 °	8.3 mm	2.5 V	350 mA	Domed	Starboard	19.05 mm	19.75 mm	34 lm/W	625 nm	25 °C	30 lm
Kingbright AAD1-9090SY28ZC		Yellow	350 mA				100 °		2.5 V	350 mA			0.354 in	0.354 in	37 lm/W	588 nm	25 °C	32 lm	12 °C/W	2-SMD Gull Wing Exposed Pad	9 mm	9 mm	Surface Mount	0.267 in	6.78 mm
Kingbright AAD1-9090SY28ZC-S	LED Module	Yellow	350 mA				135 °	8.3 mm	2.5 V	350 mA	Domed	Starboard	19.05 mm	19.75 mm		588 nm
Kingbright AAD1-9090SE9ZC/2		Red	500 mA				100 °		2.7 V	500 mA			0.354 in	0.354 in	37 lm/W	623 nm	25 °C	50 lm	12 °C/W	2-SMD Gull Wing Exposed Pad	9 mm	9 mm	Surface Mount	0.267 in	6.78 mm
Kingbright AAD1-9090SE28ZC		Red	350 mA				100 °		2.5 V	350 mA			0.354 in	0.354 in	40 lm/W	625 nm	25 °C	35 lm	12 °C/W	2-SMD Gull Wing Exposed Pad	9 mm	9 mm	Surface Mount	0.267 in	6.78 mm
Kingbright AAD1-9090BRGC-01/3		Blue Green Red		530 nm	625 nm	458 nm	135 °		2.5 V 3.2 V 3.3 V				0.354 in	0.354 in	18 lm/W 34 lm/W 43 lm/W		25 °C		9 °C/W 9 °C/W 12 °C/W	4-SMD J-Lead Exposed Pad	9 mm	9 mm	Surface Mount	0.267 in	6.78 mm	20 lm	50 lm	30 lm	350 mA	350 mA	350 mA
