5834-0 Series

Catalog

CONN PIN RCPT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness	Contact Finish Thickness	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Contact Material	Tail Type	Contact Finish	Socket Depth	Socket Depth	Accepts Pin Diameter [Min] [diameter]	Accepts Pin Diameter [Max] [diameter]	Accepts Pin Diameter [Max] [diameter]	Accepts Pin Diameter [Min] [diameter]	Flange Diameter [diameter]	Flange Diameter [diameter]	Termination	Length - Overall	Length - Overall	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]
Mill-Max Manufacturing Corp. 5834-0-15-80-23-14-10-0	-55 C	125 °C	0.25 Ám	10 Áin	0.107 "	2.72 mm	Beryllium Copper	No Tail	Gold	0.255 in	6.48 mm	0.045 "	1.65 mm	0.065 "	1.14 mm	3 mm	0.118 in	Press-Fit	0.29 in	7.37 mm	2.24 mm	0.088 "
Mill-Max Manufacturing Corp. 5834-0-15-01-23-01-10-0	-55 C	125 °C	5.08 Ám	200 Áin	0.107 "	2.72 mm	Beryllium Copper	No Tail	Tin-Lead	0.255 in	6.48 mm	0.045 "	1.65 mm	0.065 "	1.14 mm	3 mm	0.118 in	Press-Fit	0.29 in	7.37 mm	2.24 mm	0.088 "
Mill-Max Manufacturing Corp. 5834-0-15-80-23-80-10-0	-55 C	125 °C	5.08 Ám	200 Áin	0.107 "	2.72 mm	Beryllium Copper	No Tail	Tin	0.255 in	6.48 mm	0.045 "	1.65 mm	0.065 "	1.14 mm	3 mm	0.118 in	Press-Fit	0.29 in	7.37 mm	2.24 mm	0.088 "
Mill-Max Manufacturing Corp. 5834-0-15-01-23-14-10-0	-55 C	125 °C	0.25 Ám	10 Áin	0.107 "	2.72 mm	Beryllium Copper	No Tail	Gold	0.255 in	6.48 mm	0.045 "	1.65 mm	0.065 "	1.14 mm	3 mm	0.118 in	Press-Fit	0.29 in	7.37 mm	2.24 mm	0.088 "
