1761185 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN MOD JACK 16P R/A SHLD
| Part | Housing Material | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Number of Ports | Shielding | Number of Positions/Contacts | Contact Material | Mounting Type | Number of Rows | Contact Finish | Orientation | LED Color | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 16 Positions | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
 TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 8 Positions | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 8 Positions | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
 TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 4 Contacts | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 4 Contacts | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
 TE Connectivity Raychem Cable Protection | Polyester | Solder | -20 C | 80 C | Jack SDL | 1 | Shielded | 8 Positions | Phosphor Bronze | Through Hole | 1 | Gold | 90 ° | Does Not Contain LED | 50 µin | 1.27 µm | Board Guide Keyed |
