HD74AC Series
Description
AI
This series is upward compatible with the HD74HC Series, and has more than double the high-speed operation of the HD74HC Series.
Beta
⌘K
HD74AC Series
HD74AC Series
| Part | Number of Bits per Element | Mounting Type | Supplier Device Package | Logic Type | Output Type | Current - Output High, Low | Operating Temperature [Max] | Operating Temperature [Min] | Number of Elements | Voltage - Supply [Min] | Voltage - Supply [Max] | Package / Case | Package / Case | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Renesas Electronics Corporation | ||||||||||||||
 Renesas Electronics Corporation | 4 | Through Hole | 20-PDIP | Buffer Inverting | 3-State | 24 mA | 85 °C | -40 °C | 2 | 2 V | 6 V | 20-DIP | 7.62 mm | 0.3 in |
