1856/19 Series

Catalog

WIRE, HOOK UP MIL-W-16878E/1, PVC, WHITE, 20 AWG, 0.62 MM², 100 FT

Part	Cable Type	Conductor Material	Qualification	Jacket Color	Jacket (Insulation) Material	Operating Temperature [Min]	Operating Temperature [Max]	Length [x]	Length [x]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Length	Length
ALPHA WIRE 1856/19 WH005	Hook-Up	Copper Tinned	MIL-W-16878E/1	White	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
ALPHA WIRE 1856/19 VI001	Hook-Up	Copper Tinned	MIL-W-16878E/1	Violet	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C			0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V	304.8 m	1000 ft
ALPHA WIRE 1856/19 WO005	Hook-Up	Copper Tinned	MIL-W-16878E/1	White Orange Stripe	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
ALPHA WIRE 1856/19 WG001	Hook-Up	Copper Tinned	MIL-W-16878E/1		Poly-Vinyl Chloride (PVC)	-55 C	105 ░C			0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V	304.8 m	1000 ft
ALPHA WIRE 1856/19 WV005	Hook-Up	Copper Tinned	MIL-W-16878E/1	White Violet Stripe	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
ALPHA WIRE 1856/19 WN001	Hook-Up	Copper Tinned	MIL-W-16878E/1	White Brown Stripe	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C			0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V	304.8 m	1000 ft
ALPHA WIRE 1856/19 BR001	Hook-Up	Copper Tinned	MIL-W-16878E/1	Brown	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C			0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V	304.8 m	1000 ft
ALPHA WIRE 1856/19 WR005	Hook-Up	Copper Tinned	MIL-W-16878E/1	White Red Stripe	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
ALPHA WIRE 1856/19 WS005	Hook-Up	Copper Tinned	MIL-W-16878E/1	White Gray Stripe	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
ALPHA WIRE 1856/19 BL005	Hook-Up	Copper Tinned	MIL-W-16878E/1	Blue	Poly-Vinyl Chloride (PVC)	-55 C	105 ░C	100 ft	30.5 m	0.25 mm	0.01 in	20 AWG	19	32 AWG	600 V
