395-030 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 30POS 0.100
| Part | Termination Rows | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Card Type | Contact Type | Termination | Contact Material | Mounting Type | Color | Number of Positions/Bay/Row | Number of Positions | Contact Finish | Features | Read Out | Flange Feature | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Single Edge | Cantilever | Wire Wrap | Copper Alloy | Through Hole | Black | 30 | 30 | Gold | Card Guides | Single | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | Through Hole | Black | 15 | 30 | Gold | Dual | 0.25 Ám | 10 Áin | 2 | 0.156 " | 3.96 mm | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Wire Wrap | Copper Alloy | Through Hole | Black | 15 | 30 | Gold | Dual | M3 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Wire Wrap | Copper Alloy | Through Hole | Black | 15 | 30 | Gold | Dual | 0.25 Ám | 10 Áin | 2 | 0.128 " | 3.25 mm | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Wire Wrap | Copper Alloy | Through Hole | Black | 15 | 30 | Gold | Card Guides | Dual | 4-40 Threaded Insert Top Mount Opening | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | Board Edge Straddle Mount | Black | 15 | 30 | Gold | Card Extender | Dual | 0.25 Ám | 10 Áin | 2 | 0.156 " | 3.96 mm | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | Right Angle Through Hole | Black | 15 | 30 | Gold | Dual | 0.25 Ám | 10 Áin | 2 | 0.128 " | 3.25 mm | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | Through Hole | Black | 30 | 30 | Gold | Single | 4-40 Threaded Insert Top Mount Opening | 1 | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Cantilever | Solder | Copper Alloy | Through Hole | Black | 15 | 30 | Gold | Dual | 0.25 Ám | 10 Áin | 2 | 0.156 " | 3.96 mm | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | -40 C | 105 ░C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Non Specified - Single Edge | Cantilever | Solder | Copper Alloy | Through Hole | Black | 30 | 30 | Gold | Single | Flush Mount M3 Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin |
