2834499 Series

Catalog

MINI DYNAMIC HDR H 16P TIN Y-KEY

Part	Number of Rows	Insulation Material	Number of Positions Loaded	Contact Type	Insulation Height	Insulation Height	Connector Type	Fastening Type	Features	Contact Material	Mounting Type	Material Flammability Rating	Number of Positions	Insulation Color	Contact Finish - Post	Termination	Contact Shape	Shrouding	Pitch - Mating	Pitch - Mating	Style	Number of Positions
TE Connectivity Raychem Cable Protection 1-2834499-6	1	Thermoplastic	All	Male Pin	0.341 in	8.65 mm	Receptacle	Push-Pull	Solder Retention	Copper Alloy	Surface Mount Right Angle	UL94 V-0	16	Black	Tin	Solder	Square	Shrouded - 4 Wall	0.071 in	1.8 mm	Board to Cable/Wire
TE Connectivity Raychem Cable Protection 2-2834499-0	2	Thermoplastic	All	Male Pin	0.34 in	8.64 mm	Elevated Header	Push-Pull	Solder Retention	Copper Alloy	Surface Mount	UL94 V-0		Black	Tin	Solder	Square	Shrouded - 4 Wall	0.071 in	1.8 mm	Board to Cable/Wire	20
TE Connectivity Raychem Cable Protection 1-2834499-2	2	Thermoplastic	All	Male Pin	0.341 in	8.65 mm	Elevated Header	Push-Pull	Solder Retention	Copper Alloy	Surface Mount	UL94 V-0		Black	Tin	Solder	Square	Shrouded - 4 Wall	0.071 in	1.8 mm	Board to Cable/Wire	12
