T41110 Series
Circular Metric Connectors M12,FEMALE,RA,A CODE ,3P,PG9,GOLD
Manufacturer: TE Connectivity AMP Connectors
Catalog
Circular Metric Connectors M12,FEMALE,RA,A CODE ,3P,PG9,GOLD
Circular Metric Connectors M12,FEMALE,RA,A CODE ,3P,PG9,GOLD
Circular Metric Connectors M12,FEMALE,RA,A CODE ,3P,PG9,GOLD
Circular Metric Connectors M12,FEMALE,RA,A CODE ,3P,PG9,GOLD
| Part | Termination | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Ingress Protection | Primary Material | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Connector Type | Applications | Mounting Type | Number of Positions | Contact Material | Orientation | Shell Size - Insert | Current Rating (Amps) | Shell Finish | Shielding | Contact Finish - Mating | Backshell Material, Plating | Shell Material | Color | Fastening Type | Insert Material [custom] | Insert Material [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors | Screw | 0.157 in | 0.236 in | 6 mm | 4 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 8 | Zinc Alloy | A | M12-8 | 2 A | Nickel | Shielded | Gold | Brass Nickel | Brass | Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 30 VDC | ||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | Zinc Alloy | A | M12-3 | 4 A | Nickel | Unshielded | Gold | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | |||
TE Connectivity AMP Connectors | Screw | 0.157 in | 0.236 in | 6 mm | 4 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 5 | Zinc Alloy | A | M12-5 | 4 A | Nickel | Unshielded | Gold | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 60 VDC | ||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 2 | Zinc Alloy | A | M12-2 | 4 A | Nickel | Unshielded | Gold | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | ||
TE Connectivity AMP Connectors | Screw | 0.157 in | 0.236 in | 6 mm | 4 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 2 | Zinc Alloy | A | M12-2 | 4 A | Nickel | Unshielded | Gold | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | ||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | Zinc Alloy | A | M12-3 | 4 A | Nickel | Shielded | Gold | Brass Nickel | Brass | Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | |||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 4 | Zinc Alloy | A | M12-4 | 4 A | Nickel | Unshielded | Gold | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | ||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 2 | Brass | A | M12-2 | 4 A | Nickel | Unshielded | Silver | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | 2.03 µm | 80 µin | ||
TE Connectivity AMP Connectors | Screw | 0.236 in | 0.315 in | 8 mm | 6 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | 0.076 µm | 3 µin | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 2 | Zinc Alloy | A | M12-2 | 4 A | Nickel | Shielded | Gold | Brass Nickel | Brass | Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | ||
TE Connectivity AMP Connectors | Screw | 0.157 in | 0.236 in | 6 mm | 4 mm | IP67 - Dust Tight Waterproof | Metal | Backshell | Receptacle Male Pins | Industrial | Free Hanging (In-Line) | 4 | Brass | A | M12-4 | 4 A | Nickel | Unshielded | Silver | Polybutylene Terephthalate (PBT) Glass Filled | Brass | Black Silver | Threaded | Nylon | Polyamide (PA) | 85 °C | -40 C | 250 V | 2.03 µm | 80 µin |
