21_SMA-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
21_SMA-50-2-6/111_NH
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Body Finish | Body Material | Mating Cycles | Center Contact Plating | Housing Color | Connector Type | Mounting Type | Contact Termination | Connector Style | Frequency - Max [Max] | Number of Ports | Shield Termination | Center Contact Material | Fastening Type | Impedance | Cable Group | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Beryllium Copper | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Crimp | Beryllium Copper | Threaded | 50 Ohms | ||
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Beryllium Copper | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Solder | Beryllium Copper | Threaded | 50 Ohms | ||
 Huber+Suhner, Inc. | -65 ░C | 125 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Beryllium Copper | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Solder | Beryllium Copper | Threaded | 50 Ohms | 0.047 in | |
Huber+Suhner, Inc. | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Solder | Beryllium Copper | Threaded | 50 Ohms | RG-141 | |
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Beryllium Copper | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Solder | Beryllium Copper | Threaded | 50 Ohms | RG-405 (.086 Semi Rigid) | |
 Huber+Suhner, Inc. | -65 ░C | 125 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | White Bronze | Brass | 500 | Gold | Silver | Female Socket Jack | Free Hanging (In-Line) | Crimp | SMA | 18 GHz | 1 | Crimp | Beryllium Copper | Threaded | 50 Ohms | ||
 Huber+Suhner, Inc. | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Beryllium Copper | 500 | Gold | Gold | Female Socket Jack | Free Hanging (In-Line) | Solder | SMA | 18 GHz | 1 | Solder | Beryllium Copper | Threaded | 50 Ohms | RG-141 |
