4N25 Series

Catalog

NPN-OUTPUT DC-INPUT OPTOCOUPLER,1-CHANNEL,5.3KV ISOLATION,DIP ROHS COMPLIANT: YES

Part	Mounting Type	Package / Case	Package / Case	Package / Case	Supplier Device Package	Vce Saturation (Max) [Max]	Current Transfer Ratio (Min) [Min]	Current - Output / Channel	Voltage - Output (Max) [Max]	Number of Channels	Current - DC Forward (If) (Max) [Max]	Input Type	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Forward (Vf) (Typ)	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Turn On / Turn Off Time (Typ)
Vishay General Semiconductor - Diodes Division 4N25-X000	Through Hole	6-DIP	0.3 in	7.62 mm	6-DIP	500 mV	20 %	50 mA	70 V	1	60 mA	DC	100 °C	-55 °C	1.36 V	2 µs	2 µs
Vishay General Semiconductor - Diodes Division 4N25	Through Hole	6-DIP	0.3 in	7.62 mm	6-DIP	500 mV	20 %	50 mA	70 V	1	60 mA	DC	100 °C	-55 °C	1.3 V	2 µs	2 µs
Vishay General Semiconductor - Diodes Division 4N25V	Through Hole	6-DIP	0.3 in	7.62 mm	6-DIP	300 mV	20 %	50 mA	32 V	1	60 mA	DC	100 °C	-55 °C				6.7 µs	7 µs	7 µs 11 µs
Vishay General Semiconductor - Diodes Division 4N25-X017	Surface Mount	6-SMD Gull Wing			6-SMD	500 mV	20 %	50 mA	70 V	1	60 mA	DC	100 °C	-55 °C	1.36 V	2 µs	2 µs
Vishay General Semiconductor - Diodes Division 4N25-X009	Surface Mount	6-SMD Gull Wing			6-SMD	500 mV	20 %	50 mA	70 V	1	60 mA	DC	100 °C	-55 °C	1.36 V	2 µs	2 µs
Vishay General Semiconductor - Diodes Division 4N25-X009T	Surface Mount	6-SMD Gull Wing			6-SMD	500 mV	20 %	50 mA	70 V	1	60 mA	DC	100 °C	-55 °C	1.36 V	2 µs	2 µs
