VL-EPM Series
Manufacturer: VersaLogic Corporation
Catalog
SBC 1.2GHZ 2 CORE 4GB/0GB RAM
| Part | Operating Temperature (Min) | Operating Temperature (Max) | RAM Installed | RAM Capacity | Expansion Site/Bus | Watchdog Timer | Power (Watts) | Contents | Video Outputs | Core Processor | Serial Interface Count | Supported Serial Standards | Form Factor | Storage Interface | Number of Storage Interfaces | Speed | USB 2.0 Count | USB | Cooling Type | Size / Dimension Length | Size / Dimension Width | Number of Cores | Ethernet Ports | Ethernet Speed Options | Ethernet Interface | Digital I/O Lines | USB 3.0 Count | Video Outputs (DP) Count | Video Core Model | Video Core Engine | Video Core Bit Width | Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 VersaLogic Corporation | -40 °C | 85 °C | 0 GB | 4 GB | PC/104-Plus SATA | Yes | 15.5 W | Keyboard Mouse | LVDS VGA | Intel Core 2 Duo SP9300 | 4 5 | RS-232 RS-422 RS-485 | PC/104 | eUSB MiniBlade SATA 2.0 SATA2 | 2 count | 1.2 GHz | 6 count | USB 2.0 | Fan Heat Sink | 4.21 in | 3.78 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | GbE | |||||||
 VersaLogic Corporation | -40 °C | 85 °C | 0 GB | 8 GB | I2C mPCIe PCI/104-Express OneBank PCIe/104 SATA SPI/SPX | Yes | 6.75 W | Keyboard Mouse | DP Mini Display Port VGA | Intel Atom E3815 | 2 | RS-232 RS-422 RS-485 | PC/104 | mSATA SATA SATA 2.0 | 1.46 GHz | 5 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 1 | 2 | 1000Mbps 100Mbps 10Mbps | 18 lines | 1 count | 2 | ||||||
 VersaLogic Corporation | 0 °C | 60 °C | 8 GB | 8 GB 16 GB | I2C microSD mPCIe PC/104-Plus SATA SPI/SPX | Yes | 13.3 W | DP miniDP | Intel Core i7-7600U | 4 | RS-232 RS-422 RS-485 | PC/104 | microSD Mini PCIe mSATA SATA SATA 3.0 SPI | 2.8 GHz 3.9 GHz | 4 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | 8 lines | 2 count | 2 | |||||||
 VersaLogic Corporation | -40 °C | 85 °C | PC/104-Plus | 3.38 W | LVDS VGA | PC/104-Plus | Heat Sink | 3.543 in | 3.779 in | SM750 | 2D graphics engine | 128 Bit | Module Video Card | |||||||||||||||||||
 VersaLogic Corporation | -40 °C | 85 °C | 0 GB | 4 GB | PC/104-Plus SATA | Yes | 15.5 W | Keyboard Mouse | LVDS VGA | Intel Core 2 Duo SP9300 | 4 5 | RS-232 RS-422 RS-485 | PC/104 | eUSB MiniBlade SATA 2.0 SATA2 | 2 count | 1.2 GHz | 6 count | USB 2.0 | Fan Heat Sink | 4.21 in | 3.78 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | GbE | |||||||
 VersaLogic Corporation | -40 °C | 85 °C | 8 GB | 8 GB 16 GB | I2C microSD mPCIe PCI/104-Express OneBank PCIe/104 SATA SPI/SPX | Yes | 12 W | Keyboard Mouse | DP Mini Display Port | Intel Core i3 Intel Core i3-7100U | 4 | RS-232 RS-422 RS-485 | PC/104 | microSD mSATA SATA SATA 3.0 | 2.4 GHz | 4 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | 8 lines | 2 count | 2 | ||||||
 VersaLogic Corporation | -40 °C | 85 °C | 4 GB | 4 GB 16 GB | I2C microSD mPCIe PCI/104-Express OneBank PCIe/104 SATA SPI/SPX | Yes | 12.5 W | Keyboard Mouse | DP Mini Display Port | Intel Core i5 Intel Core i5-7300U | 4 | RS-232 RS-422 RS-485 | PC/104 | microSD mSATA SATA SATA 3.0 | 3.5 GHz | 4 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | 8 lines | 2 count | 2 | ||||||
 VersaLogic Corporation | 0 °C | 60 °C | 16 GB | 16 GB | I2C microSD mPCIe PC/104-Plus SATA SPI/SPX | Yes | 13.3 W | DP miniDP | Intel Core i7-7600U | 4 | RS-232 RS-422 RS-485 | PC/104 | microSD Mini PCIe mSATA SATA SATA 3.0 SPI | 2.8 GHz 3.9 GHz | 4 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | 8 lines | 2 count | 2 | |||||||
 VersaLogic Corporation | 0 °C | 60 °C | 0 GB | 4 GB | PC/104-Plus SATA | Yes | 21.3 W | Keyboard Mouse | LVDS VGA | Intel Core 2 Duo SP9300 | 4 5 | RS-232 RS-422 RS-485 | PC/104 | eUSB MiniBlade SATA 2.0 SATA2 | 2 count | 2.26 GHz | 6 count | USB 2.0 | Fan Heat Sink | 4.21 in | 3.78 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | GbE | |||||||
VersaLogic Corporation | -40 °C | 85 °C | 0 GB | 0 GB 16 GB | I2C microSD mPCIe PCI/104-Express OneBank PCIe/104 SATA SPI/SPX | Yes | 12 W | Keyboard Mouse | DP Mini Display Port | Intel Core i3 Intel Core i3-7100U | 4 | RS-232 RS-422 RS-485 | PC/104 | microSD mSATA SATA SATA 3.0 | 2.4 GHz | 4 count | USB 2.0 USB 3.0 | Heat Plate | 4.23 in | 3.77 in | 2 | 2 | 1000Mbps 100Mbps 10Mbps | 8 lines | 2 count | 2 |
