6609107 Series
Manufacturer: TE Connectivity Corcom Filters
Beta
⌘K
PWR ENT MOD RCPT IEC320-C14 PNL
| Part | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Connector Style | Features | Current Rating - Appliance Inlet | Accomodates a Fuse | Approval Agency | Voltage Rating - Appliance Inlet | Fuse Holder, Drawer | Panel Thickness [custom] | Panel Thickness [custom] | Connector Type | Termination | Termination | Termination | Current Rating - Filter | Mounting Type | Filter Type | Panel Cutout Dimensions | Panel Thickness [Min] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Max] | Switch Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Corcom Filters | 66.04 mm | 26.92 mm | IEC 320-C14 | Conversion Clip Voltage Selector | 6 A | CSA UL VDE | 120 VAC | Fuse Holder | 0.225 in | 5.72 mm | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 6 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | |||||||
TE Connectivity Corcom Filters | IEC 320-C14 | 6 A | CSA UL VDE | 120 VAC | Twin Fused | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 6 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | |||||||
TE Connectivity Corcom Filters | 66.04 mm | 26.92 mm | IEC 320-C14 | Conversion Clip Shielded Voltage Selector | 6 A | CSA UL VDE | 120 VAC | Fuse Holder | 0.225 in | 5.72 mm | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 6 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Switch On-Off | ||||||
TE Connectivity Corcom Filters | 66.04 mm | 26.92 mm | IEC 320-C14 | Conversion Clip Shielded | 3 A | CSA UL VDE | 120 VAC | Fuse Holder | 0.225 in | 5.72 mm | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 3 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Switch On-Off | ||||||
 TE Connectivity Corcom Filters | IEC 320-C14 | Conversion Clip Shielded | 3 A | CSA UL VDE | 120 VAC | Fuse Holder | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 3 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Switch On-Off | |||||
 TE Connectivity Corcom Filters | IEC 320-C14 | Shielded | 10 A | CSA UL VDE | 120 VAC | Twin Fused | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 10 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | ||||||
 TE Connectivity Corcom Filters | IEC 320-C14 | Shielded | 3 A | CSA UL VDE | 120 VAC | Twin Fused | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 3 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Switch On-Off | |||||
 TE Connectivity Corcom Filters | IEC 320-C14 | Conversion Clip Shielded Voltage Selector | 3 A | CSA UL VDE | 120 VAC | Fuse Holder | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 3 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Switch On-Off | |||||
TE Connectivity Corcom Filters | IEC 320-C14 | Shielded Voltage Selector | 6 A | CSA UL VDE | 120 VAC | Twin Fused | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 6 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | ||||||
 TE Connectivity Corcom Filters | IEC 320-C14 | Shielded | 10 A | CSA UL VDE | 120 VAC | Twin Fused | Receptacle Male Blades - Module | Quick Connect | 0.187 " | 4.7 mm | 10 A | Panel Mount Snap-In | Filtered (EMI RFI) - Commercial | Variable Size | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | Switch On-Off |
