180-026 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB HD PLUG 26POS PNL MNT
| Part | Contact Material | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Connector Style | Flange Feature | Contact Finish | Current Rating (Amps) | Contact Finish Thickness | Material Flammability Rating | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Contact Type | Number of Rows [custom] | Number of Positions | Connector Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Features | Color | Termination | Shell Material, Finish | Note | Contact Form |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | 4-40 | Gold | 5 A | Flash | UL94 V-0 | Steel | Yellow Chromate Plated | Signal | 3 | 26 | Plug Male Pins | 2 | DA A | Shielded | |||||
NorComp Inc. | Polyester Glass Filled | 100 °C | -50 °C | Panel Mount Through Hole | D-Sub High Density | Housing/Shell (Unthreaded) | Gold | 2 A | Flash | UL94 V-0 | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Black | Solder | |||||||
 NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | Cable Side (4-40) | Gold | 5 A | Flash | UL94 V-0 | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Shielded | Nickel Plated Steel | ||||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | Cable Side (4-40) | Gold | 2 A | Flash | UL94 V-0 | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Black | ||||||||
NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | Cable Side (4-40) | Gold | 5 A | Flash | UL94 V-0 | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Shielded | |||||||
 NorComp Inc. | 100 °C | -50 °C | Free Hanging (In-Line) | D-Sub High Density | Cable Side (4-40) | Signal | 3 | 26 | Receptacle for Female Contacts | 2 | DA A | Shielded | Contacts Not Included | ||||||||||||
 NorComp Inc. | Polyester Glass Filled | 100 °C | -50 °C | Panel Mount Through Hole | D-Sub High Density | Board Side (4-40) | Gold | 2 A | Flash | UL94 V-0 | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Black | Solder | |||||||
NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | Housing/Shell (Unthreaded) | Gold | 5 A | Flash | UL94 V-0 | Steel | Yellow Chromate Plated | Signal | 3 | 26 | Plug Male Pins | 2 | DA A | Shielded | |||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | Housing/Shell (Unthreaded) | Gold | 2 A | Flash | UL94 V-0 | Signal | 3 | 26 | Plug Male Pins | 2 | DA A | Grounding Indents | Black | |||||||
NorComp Inc. | Brass | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | Panel Mount | D-Sub High Density | 4-40 | Gold | 5 A | Flash | UL94 V-0 | Steel | Yellow Chromate Plated | Signal | 3 | 26 | Receptacle Female Sockets | 2 | DA A | Shielded | Stamped |
