CDFR13W Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 13POS R/A SLDR
| Part | Dielectric Material | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Shell Material, Finish | Ingress Protection | Termination | Connector Style | Connector Type | Shell Size, Connector Layout | Shell Size, Connector Layout | Number of Rows [custom] | Features | Number of Positions [custom] | Number of Positions [custom] | Contact Finish | Flange Feature | Mounting Type | Material Flammability Rating | Contact Type | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Flash | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Plug Male Pins | 3 | 13C3 13W3 | 2 | Board Lock Grounding Indents Mounting Brackets | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Flash | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | Board Lock Mounting Brackets | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Plug Male Pins | 3 | 13C3 13W3 | 2 | Grounding Indents | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | 30 Áin | 0.76 Ám | |
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Flash | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Flash | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | |||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | Board Lock Mounting Brackets | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | 30 Áin | 0.76 Ám | |
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Flash | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Plug Male Pins | 3 | 13C3 13W3 | 2 | Board Lock Grounding Indents Mounting Brackets | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Receptacle Female Sockets | 3 | 13C3 13W3 | 2 | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | Brass | 85 °C | -25 °C | Nickel Plated Steel | IP67 - Dust Tight Waterproof | Solder | Combo D-Sub | Plug Male Pins | 3 | 13C3 13W3 | 2 | Grounding Indents | 10 | 3 | Gold | 4-40 Mating Side Female Screwlock | Panel Mount Right Angle Through Hole | UL94 V-0 | Signal and Power | 30 Áin | 0.76 Ám |
