S18SP6 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSOR, S18 SERIES, RECEIVER, OPPOSED, 20M, PNP, 10-30VDC, QUICK DISCONNECT
| Part | Ingress Protection | Connection Method | Response Time | Sensing Method | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Operating Temperature [Max] | Operating Temperature [Min] | Output Configuration | Light Source | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | Through-Beam | 10 VDC | 30 VDC | 2000 cm | 787.402 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared LED | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Cable | 3 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | 2 m | 78.74 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON - Selectable | Infrared (950nm) | 354.33 in | 9 m |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Cable | 3 ms | Polarized Retroreflective | 10 VDC | 30 VDC | 2 m | 78.74 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON - Selectable | Red (680nm) | 354.33 in | 9 m |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Cable | 3 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | 2 m | 78.74 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared (950nm) | 78.74 " | 2 m |
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | Polarized Retroreflective | 10 VDC | 30 VDC | 2 m | 78.74 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Red LED | ||
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Cable | 3 ms | Diffuse | 10 VDC | 30 VDC | 30 cm | 11.811 " | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared (880nm) | 78.74 " | 2 m |
 BANNER ENGINEERING | IEC IEC IP67 IEC IP69K IP67 IP69K NEMA 6P | Connector | 3 ms | Background Suppression | 10 VDC | 30 VDC | 10 cm | 3.937 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON - Selectable | Infrared (880nm) | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | 2 m | 78.74 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared LED | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | Diffuse | 10 VDC | 30 VDC | 10 cm | 3.937 in | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared LED | ||
 BANNER ENGINEERING | IEC IEC IP69K IP69K NEMA 6P | Connector | 3 ms | Diffuse | 10 VDC | 30 VDC | 30 cm | 11.811 " | 70 °C | -40 C | PNP - Dark-ON/Light-ON | Infrared LED |
